Deskripsi

Komatsu Forklift FB15 | 1.5 ton
TRIGUNA.ID support unit, parts, service, rental, maintenance contract, overhaul, reconditioned Komatsu Forklift FB15 | 1.5 ton
Specification unit Komatsu Forklift FB15 | 1.5 ton

Characteristics

Genseal
Model : FB15U-12.
Power Type : Electric.
Operation Type : Sit-Down.
Capacity @ 24 in (600 mm) Load Center : 3,000 lbs.
Load Distance From Center Axle (2 Stage) : 15.9 in
Wheelbase : 55.5 in

Weight

however,  Service Weight : 6,910 lbs.
Axle Loading – Loaded Front : 8,740 lbs.
Loaded Rear : 1,170 lbs.
Unloaded Front : 3,510 lbs.
Rear : 3,400 lbs.

Tires

Tire Type : Solid Pneumatic
Size – Front : 18 x 7-8
Rear : 16 x 6-8

Number of Wheels, Front/Rear : 2x / 2
Tread – Front 37.0 in : 37.0 in
Tread – Rear : 34.1 in

Dimension

In this paragraph, Tilting Angle, Forward/Backward : 6 / 10 deg
Mast Height – Lowered : 84.4 in
Mast Height – Extended : 167.5 in

Firstly, Free Lift Height : 5.9 in
Maximum Fork Height : 129.9 in
Height Overhead Guard : 81.5 in

Secondly, Length, with Standard Forks : 123.2 in
Length to Fork Face : 81.1 in
Overall Width at Drive Tires : 43.7 in

Thirdly, Forks, Thickness x Width x Length : 1.4 x 3.9 x 42.1 in
Carriage Width/ITA Class : 38.2 in / II
Ground Clearance, Under Mast : 3.7 in

Ground Clearance, Center of Wheelbase : 4.9 in
Right Angle Stacking Aisle : 124.4 / 132.2 in
Turning Radius, Outside : 68.9 in

Performance

Travel Speed, Loaded/Unloaded : 10.0 / 11.0 mph
Lifting Speed, Loaded/Unloaded : 66.9 / 118.1 fpm
Lowering Speed, Loaded/Unloaded : 88.6 / 108.3 fpm

most importantly, Maximum Drawbar Pull, Loaded : 2,150 lbs.
lass=”yoast-text-mark” />>Maximum Gradeability : 19%
Service Brake, Operation/Control : Foot / Hydraulic

Parking Brake, Operation/Control : Hand / Mechanical
Steering Type : Fully Hydrostatic Power Steering

Drive

Drive Motor (AC) : 6.0 x 2 HP
Pump Motor (AC) : 12.1 HP
Battery Voltage : 48 V

Moreover, Battery Capacity, Maximum : 600 Ah/6hr
Minimum Battery Weight : 1,590 lbs.
Maximum Battery Weight : 2,100 lbs

Other

In conclusion, Drive Motor Control : AC Inverter
Relief Pressure – Attachment : 2,300 psi
Hydraulic Oil Capacity
