Komatsu Forklift FD160 | 16 ton

Characteristics

Model : FH100-1
Power Type : Diesel
Operation Type : Sit Down

Rated Capacity : 10000 kg
Rated Load Center : 24 in
Load Distance, Front Axle to Fork Face : 30.3 in
Wheelbase 120.1 in

Weight

Service Weight : 32,055 lbs.
Axle Loading / Loaded front : 47,300 lbs.
Loaded rear : 5,479 lbs.

Axle Loading / Unloaded front : 17,273 lbs.
Unloaded rear : 14,782 lbs.

Tires

Tire Type : Pneumatic
Tire Size – Front : 9.00-20-14PR
Rear : 9.00-20-14PR

Number of Wheels, Front / Rear (x=Driven) : 4x/2
Tread – Front : 66.9 in
Rear : 74.8 in

Dimension

Tilting Angle, Forward / Backward : 6/12 degree
Mast Height, Lowered : 133.5 in
Standard Free Lift : 0

Standard Lift Height : 157.5 in
Mast Height, Extended : 212.6 in
Height Overhead Guard : 113.4 in

Length, with Standard Forks : 231.3 in
Length to Fork Face : 177.4 in
Width, at Tire, Double : 95.7 in

Forks – Thickness x Width x Length : 3.0 x 6.7 x 53.9 in
Fork Carriage Class : Pin Mount
Width, Fork Carriage : 84.0 in

Ground Clearance, Under Mast : 10.2 in
Ground Clearance, Center of Wheelbase : 13.1 in
Turning Radius : 165.4 in

Performance

Travel Speed, Loaded : 14.9 mph
Travel Speed, Unloaded : 15.5 mph
Lifting Speed, Loaded : 88.6 fpm

Lifting Speed, Unloaded : 93.5 fpm
Lowering Speed, Loaded : 86.6 fpm
Lowering Speed, Unloaded : 108.3 fpm

Maximum Drawbar Pull : 17,175 lbs.
Maximum Gradeability : 30 %
Service Brake, Operation / Control : Foot/Hydraulic

Parking Brake, Operation / Control : Hand/Mechanical
Steering Type : FHPS

Engine

Komatsu engine : SAA4D107E-3-A
Rated Output (SAE Net) : 100 kW
Rated RPM : 2,200 min-1

Maximum Torque (SAE Net) : 620 HP
No. Of Cylinders / Displacement : 4 / 272 in3
Fuel Tank Capacity : 73.9 US gal
